✅ CCL 232B Analog EPABX Intercom System Specifications
📞 Overview
The CCL 232B Analog EPABX System is an ideal communication solution for small to mid-sized offices, apartments, clinics, schools, and commercial establishments. It supports 2 CO (Central Office) Lines and 24 Extensions, expandable up to 32 Extensions, providing flexibility for future growth.
✅ Technical Specifications
| Specification | Details |
|---|---|
| Model | CCL 232B |
| System Type | Analog EPABX Intercom System |
| Trunk Line Capacity | 2 CO (PSTN) Analog Lines |
| Extension Capacity | 24 Extensions (Expandable to 32 Extensions with expansion module) |
| Power Supply | 230V AC ±10%, 50Hz |
| Power Consumption | Less than 25W |
| Extension Interface | 2-wire Analog (RJ11 Connectors) |
| Trunk Interface | 2-wire Analog (RJ11 Connectors) |
| Expandable Modules | Supports additional extension cards for expansion to 32 extensions |
✅ Key Features
| Feature | Description |
|---|---|
| Intercom Calls | Free internal communication between extensions |
| External Call Access | Extensions can access CO Lines for external calls (with authorization) |
| Call Transfer | Transfer calls between extensions (both internal and external) |
| Call Hold with Music | Hold a call with Music on Hold (MOH) function; supports external music input |
| Call Pick-Up | Pick up a call ringing at another extension (group or directed pick-up) |
| Parallel Ringing | Incoming trunk calls can ring on multiple extensions simultaneously |
| Hotline (Direct Line) | Direct dialing to a programmed extension or external number when lifting handset |
| Conference Calling | 3-party conference (1 external + 2 internal, or all internal) |
| Do Not Disturb (DND) | Temporarily block incoming calls at an extension |
| Caller Line Identification (CLI) | Supports CLI on analog CO Lines (if equipped with CLI feature) |
| Call Restriction | Control outgoing calls on extensions (Local, STD, ISD bar) |
| Trunk Hunting | Automatic selection of free trunk lines for outgoing calls |
| Remote Programming | Programming via DTMF telephone from operator extension |
| Power Failure Transfer | Automatic transfer of CO line to specific extension in case of power failure |
✅ Physical & Environmental Details
| Parameter | Details |
|---|---|
| Installation | Wall mount or desktop configuration |
| Cabinet Material | ABS Plastic or Metal (varies by model batch) |
| Operating Temperature | 0°C to 50°C |
| Humidity | 10% to 90% RH (Non-condensing) |
| Dimensions | Approx. 300mm x 220mm x 90mm (varies by version) |
| Weight | Approx. 3 kg (without battery backup) |
✅ Ports & Connectivity
| Type | Details |
|---|---|
| CO Line Inputs | 2 RJ11 Ports |
| Extension Outputs | 24 RJ11 Ports (Expandable to 32) |
| MOH Input | External audio input for Music on Hold |
| Expansion Slots | Slots for expansion cards/modules to add extensions |
✅ Applications
- Small to Medium Enterprises (SMEs)
- Clinics & Hospitals
- Educational Institutions
- Hotels / Guest Houses
- Housing Societies / Apartments
- Retail & Commercial Spaces
✅ Programming & Configuration
| Method | Details |
|---|---|
| Programming Access | From Operator / Admin Extension (default: Ext 1) |
| Programming Method | Via standard analog telephone with DTMF tones |
| Programmable Options | Hotline setup, Extension Grouping, Call Barring, CLI, DND, Call Forwarding, etc. |
✅ Optional / Advanced Features (If Supported)
| Feature | Details |
|---|---|
| Auto-Attendant / IVR | Optional feature for greeting callers and routing calls |
| Battery Backup | External battery connection for uninterrupted operation during power failures |
| CLI Memory | Memory for storing Caller ID details (if supported by the system) |
| Call Logging / Reports | Basic Call Detail Record (CDR) functionality (optional) |
✅ Package Contents
- 1 x CCL 232B EPABX Main Unit
- User Manual / Installation Guide
- RJ11 Connectors / Wiring (if supplied)
- Mounting Accessories (Wall mount brackets if applicable)
🚀 Summary
The CCL 232B Analog EPABX Intercom System (2 CO Line + 24 Extensions) expandable to 32 Extensions is a reliable, scalable solution for internal and external voice communication. It offers all essential telephony features, simple programming, and expandability to meet future needs.
