The Grandstream GWN7703 is a 24-port unmanaged Gigabit Ethernet switch designed for high-performance networking in home offices and small-to-medium businesses. It offers plug-and-play functionality with no configuration required, making it ideal for expanding network connectivity quickly and efficiently.
🔧 Key Specifications
-
Ports: 24 × 10/100/1000 Mbps RJ45 ports with auto-negotiation and auto MDI/MDIX
-
Switching Capacity: 48 Gbps
-
MAC Address Table: 8K entries
-
Jumbo Frame Support: Up to 10 KB
-
QoS Support: 802.1p/DSCP with default strict priority
-
Flow Control: IEEE 802.3x
-
Storm Control: Broadcast/Multicast/Unicast (fixed at 100 Mbps)
-
LED Indicators:
-
Per port: Link/Activity (Green)
-
Per device: Power (Green)
-
⚙️ Physical & Power Details
-
Enclosure: Metal
-
Mounting Options: Desktop or rack-mountable
-
Power Supply: Internal 100–240V AC, 50/60Hz, 18W
-
Max Power Consumption: 13W @ 220V/50Hz
-
Dimensions: 280 × 180 × 44 mm
-
Weight: 1.35 kg (unit), 1.95 kg (with packaging)
🌐 Standards & Compliance
-
Network Standards: IEEE 802.3i, 802.3u, 802.3ab, 802.3x, 802.1p
-
Compliance Certifications: FCC, CE, RCM, IC, UKCA
🌡️ Environmental Specifications
-
Operating Temperature: 0°C to 40°C
-
Storage Temperature: -20°C to 60°C
-
Operating Humidity: 10% to 90% (non-condensing)
-
Storage Humidity: 10% to 90% (non-condensing)
📦 Package Contents
-
GWN7703 24-Port Gigabit Unmanaged Switch
-
1.2m AC Power Cable
-
Rack-Mounting Brackets
-
4 × Rubber Feet
-
Quick Installation Guide
