Here is a detailed specification for a Hand Held Metal Detector, typically used for security screening, detecting concealed metal objects in various applications like airports, events, schools, or at security checkpoints:
🛠️ Hand Held Metal Detector Specification
| Parameter | Specification |
|---|---|
| Product Name | Hand Held Metal Detector |
| Type | Portable, Non-contact Security Scanner |
| Detection Sensitivity | Detects metal objects ranging from small items (e.g., coins, pins) to larger items (e.g., knives, guns) |
| Sensitivity Range | 5 – 10 cm for small objects (varies depending on metal type and object size) |
| Operating Frequency | 22 kHz to 30 kHz |
| Detection Modes | Audio alert (beep sound) and vibration alert |
| Alarm Indicators | – Audible Alarm: High-pitched beep sound for detection – Vibration Alarm: Silent mode for discreet use – LED Indicator: Typically red/green to show power or detection |
| Power Supply | – Battery Type: 9V Alkaline battery (standard) or rechargeable lithium-ion battery |
| Battery Life | – 9V Alkaline: Up to 40 hours of continuous use – Rechargeable Lithium-ion: Up to 12-18 hours on a full charge |
| Charging Time | Approximately 4-6 hours (rechargeable models) |
| Low Battery Indicator | Yes – Alert when battery is low |
| Dimensions (L × W × H) | 410 mm × 85 mm × 40 mm (varies by model) |
| Weight | 250 – 400 grams (lightweight for easy handling) |
| Material | ABS Engineering Plastic (Impact-resistant and durable) |
| Operating Temperature | -10°C to +50°C |
| Humidity Range | 95% RH (Relative Humidity) |
| Environmental Protection | IP65 or IP66 rated for dust and water resistance |
| Ergonomics | Lightweight, easy-grip handle for extended use without fatigue |
| Compliance | CE, ISO 9001, FCC, ROHS, and other safety certifications |
