The Onetouch OT-IP-LP-C9 is a sophisticated 7-inch Touch Screen Smart Video Entry Station designed for modern building security and visitor management. It combines advanced authentication methods, robust access control features, and seamless integration capabilities, making it ideal for lobbies, gated communities, and commercial premises.
📱 Key Specifications
-
Display: 7-inch Touch IPS LCD
-
Camera: 3MP Dual Camera with wide-angle lens
-
Night Vision: High-intensity white LEDs
-
Authentication Methods:
-
Face Recognition
-
QR Code scanning
-
Bluetooth Low Energy (BLE)
-
-
Access Control:
-
Mifare / NFC card reader
-
3 relay inputs and 3 relay outputs
-
Wiegand port for integration with UHF readers
-
-
Intercom Functionality: Touch keys to dial indoor station and mobile app
-
Connectivity:
-
Power over Ethernet (PoE) 802.3af
-
-
Installation: Flush mount
-
Ingress Protection: IP65 rated
-
Build: Metal finish
🔌 Integration & Expandability
-
Relay Ports: 3 inputs and 3 outputs for controlling doors and gates
-
Wiegand Port: Allows integration with UHF readers for gate automation
-
Mobile App Integration: Supports intercom and remote unlocking via the Onetouch mobile app
-
Visitor Management: Capture visitor snapshots and maintain logs
