The Panasonic VL-VA514SX is a 4-button outdoor video door phone (VDP) unit designed for multi-tenant buildings, such as apartments, row houses, and small commercial complexes. It offers a combination of durability, high-definition video, and flexible integration options. Here’s a detailed overview of its specifications and features:
🔑 Key Features
-
4-Button Design: Allows visitors to call up to four different units directly, with customizable name tags for each button.
-
2MP High-Definition Camera: Equipped with a 1/3″ CMOS sensor, providing clear video quality.
-
Wide Viewing Angle: Offers a diagonal viewing angle of approximately 155°, horizontal 120°, and vertical 60°, ensuring comprehensive coverage.
-
Color Night Vision: Features white LED lighting to provide clear color images even in low-light conditions.
-
Hands-Free Communication: Built-in omnidirectional microphone with noise suppression and echo cancellation for clear audio.
-
RFID Card Unlock Support: Enables access control using RFID cards.
-
Tamper Alert: Detects and alerts in case of tampering with the unit.
-
Weatherproof and Vandal-Proof: Rated IP65 for dust and water resistance, and IK10 for impact resistance, ensuring durability in various environments.
-
Analog and Hybrid Monitor Support: Compatible with both analog and AHD monitors, with a toggle switch to select the desired mode.
-
Exit Button Support: Allows integration with an exit button for convenient egress.
📐 Technical Specifications
-
Model Number: VL-VA514SX
-
Power Source: DC 14.5V 1A, 50/60 Hz
-
Power Consumption: Standby: <3.0 W; Operating: <10.0 W
-
Dimensions (H x W x D): 182 x 91 x 43 mm (excluding protrusions)
-
Weight: Approximately 351 g
-
Operating Environment: Temperature: -20°C to +70°C; Humidity: 10% to 90% (non-condensing)
-
Camera Resolution: 2MP (1/3″ CMOS sensor)
-
Video Output Resolution: CVBS: 720 x 576; AHD: 1024 x 600
-
Installation Method: Surface or flush mount
-
Lock Connection Relay: 1 Relay (NO/COM/NC)
-
Minimum Illumination Required: 1 lx (within approximately 50 cm from the camera lens)
-
Lighting Method: White LED
-
IP/IK Rating: IP65 / IK10
🏢 Compatibility
The VL-VA514SX is compatible with Panasonic monitor models such as VL-SA71SX, VL-SA72SX, and VL-SA611SX. The toggle switch allows selection between AHD and analog monitor modes, providing flexibility in system integration.
